Flexo® PET
Flexo PET® - The Expandable Braided Sleeve for Uncompromising Cable Protection
Why does Flexo PET stand out as…
Why choose Flexo PET over standard split tubing or electrical tape?
- Formidable installation efficiency: Its "push-back" elasticity allows for fluid sleeving. In practice, you can wire 3 times faster than with tedious manual taping.
- Resistance to the test of time: Where tapes peel off and rigid conduits eventually crack under vibration, PET retains its shape memory and UV protection for the long haul.
- Strategic lightness: Essential for aerospace or automotive sectors, its feather-light structure reduces the total mass of your systems without sacrificing protection.
- Color Coding and Identification: With one of the widest palettes on the market, Flexo PET allows you to segment your circuits visually, making troubleshooting and maintenance nearly instantaneous.
- Finish and brand image: A clean, color-coordinated installation reflects your professionalism and enhances the perceived value of your equipment.
- Measurable ROI: By limiting cable failures and machine downtime, Flexo PET pays for itself within the first few hours of service.
Technical Focus: The importance of heat treatment
What sets an Eurosleeving product apart from generic solutions is our post-braiding heat treatment. This process stabilizes the polymer's shape memory: once the sleeve is stretched, it naturally returns to its original diameter. The result: a firm, non-slip hold without the need for excessive cable ties.
Customization: A color palette for every application
One of the greatest strengths of the Flexo PET range is its diversity of finishes. Beyond standard black and grey, we offer a wide variety of solid colors, neons, and even custom blends. This diversity not only respects your machine's aesthetics but also creates an infallible visual tracking system for your technicians, significantly reducing the risk of errors during field interventions.
Where to use Flexo PET braided sleeving?
Thanks to its mechanical properties, Flexo PET has become the trusted partner for many high-tech sectors:
- Automotive & Racing: Securing critical under-the-hood wiring harnesses against vibration and friction.
- IT Infrastructure & Data Centers: Optimizing airflow and facilitating visual identification for dense network architectures.
- Marine Environments: Rot-proof protection that fears neither salt nor corrosive humidity.
- Events & Audiovisual: Clean grouping of control room cabling with a matte finish that prevents glare under stage lights.
- Precision Robotics: Accompanies the repeated movements of articulated arms without hindering their range of motion.
Compliance and Technical Data
Choosing Eurosleeving means guaranteeing your clients total compliance with global safety requirements:
- Fire Safety: Self-extinguishing material rated UL94 V-0/V-2.
- Environmental Commitment: Halogen-free formulation, compliant with RoHS and REACH standards.
- Thermal Stability: Operational from -70°C up to +125°C, with a safe melting point at +250°C.
- Physical Properties: Resistant to hydrocarbons, chemical cleaning agents, and premature aging caused by UV rays.
Product Sizes
| Part Number | Diameter Inside |
Expansion Minimum |
Expansion Maximum |
Wall Thickness |
Mini Spool |
Bulk Spool |
|---|---|---|---|---|---|---|
| PTN0.06 | 1,6 mm | 1,2 mm | 2,4 mm | 0,6 mm | 76,2 m | 304,9 m |
| PTN0.13 | 3,2 mm | 2,4 mm | 6,4 mm | 0,6 mm | 68,6 m | 304,9 m |
| PTN0.25 | 6,4 mm | 3,2 mm | 11,1 mm | 0,6 mm | 61,0 m | 304,9 m |
| PTN0.38 | 9,5 mm | 4,8 mm | 12,7 mm | 0,6 mm | 38,1 m | 152,4 m |
| PTN0.50 | 12,7 mm | 6,4 mm | 19,1 mm | 0,6 mm | 30,5 m | 152,4 m |
| PTN0.63 | 15,9 mm | 9,5 mm | 25,4 mm | 0,6 mm | 30,5 m | 152,4 m |
| PTN0.75 | 19,1 mm | 12,7 mm | 31,8 mm | 0,6 mm | 22,9 m | 76,2 m |
| PTN1.00 | 25,4 mm | 15,9 mm | 41,3 mm | 0,6 mm | 19,8 m | 76,2 m |
| PTN1.25 | 31,8 mm | 19,1 mm | 44,5 mm | 0,6 mm | 15,2 m | 76,2 m |
| PTN1.50 | 38,1 mm | 25,4 mm | 54,0 mm | 0,6 mm | 12,2 m | 61,0 m |
| PTN1.75 | 44,5 mm | 31,8 mm | 69,9 mm | 0,6 mm | 9,1 m | 61,0 m |
| PTN2.00 | 50,8 mm | 38,1 mm | 88,9 mm | 0,6 mm | 15,2 m | 61,0 m |
| PTN2.50 | 63,5 mm | 44,5 mm | 92,1 mm | 0,6 mm | 15,2 m | 61,0 m |
| PTN3.00 | 76,2 mm | 63,5 mm | 120,7 mm | 0,6 mm | 15,2 m | 30,5 m |
Your Questions on Using Flexo PET
What is the secret to a clean cut without fraying? To ensure the integrity of the braid, avoid standard scissors. The use of a hot knife is essential: the heat will cauterize the tips of the monofilaments during the cut, instantly welding the end for a flawless and durable finish.
Is it at risk of becoming brittle under sun exposure? Not at all. The PET we use incorporates stabilizers that protect it against photochemical degradation. Whether on a roof or in an exposed engine compartment, the sleeve maintains its flexibility and mechanical strength without becoming brittle.
Can it be installed on a cable where the connector is already soldered? Yes, that's the whole point of its large expansion capacity. However, if the connector is truly disproportionate to the cable, insertion can be difficult. In this specific case, or for retrofitting without disassembly, we would direct you toward our Flexo F6 solution, which wraps directly around the cable.
What is its actual resistance to pests? PET is an effective barrier against common abrasion, but it is not a chemical repellent for rodents. If your installation is located in a high-infestation area (agricultural settings, buried technical conduits), we can offer specific reinforced or metal variants.
Consult the technical data sheet
Every project has its specific needs. Our technicians are here to help you validate the chemical or mechanical endurance of Flexo PET based on your actual constraints.
Need to see for yourself? Contact us to receive your free samples. Test Eurosleeving flexibility and robustness in real conditions before validating your production run.
